Engine model: WD615.47, Euro II, 371HP
Optional: WD615.62 / WD615.87 / WD615.69 / WD615.47
Overall Dimension:10820*2550*3900mm
Product Features
Truck Model |
ZZ1317N3667A |
ENGINE |
Make: SINOTRUK Diesel 4-stroke direct injection diesel engine Engine model: WD615.47, Euro II, 371HP With Oil Bath Filter System 6-cylinder in-line with water cooling, turbo-charging and intercooling Displacement: 9.726 L Optional: WD615.62 / WD615.87 / WD615.69 / WD615.47 |
Cabin |
HW76 cab, with one sleeper and two seats, 2-arm windscreen wiper system with three speeds, damped adjustable driver’s seat, with heating and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn, air conditioner, with transverse stabilizer,with 4-point support fully floating suspension + shock absorber. High steel bumper, With inter-cooler fence Option: air suspension driver’s seat, high roof double bunk, fire extinguisher, warning light |
Clutch |
Single-plate dry coil-spring clutch, hydraulically operating with air assistance |
Transmission |
HW15710 / HW19710, 10F & 2R Ratio: 14.28, 10.62, 7.87, 5.88, 4.38, 3.27, 2.43, 1.80, 1.34, 1.00, 13.91(R1), 3.18(R2) |
Propeller Shaft |
Double universal joint propeller shaft with gear-shaped coupling flange |
Front Axle |
HF9, 2 X 9000 KGS Steering with double T-cross section beam Optional:HF7, 2 x 7000kgs, drum type |
Rear Axle |
HC16,2 x 16000 KGS Pressed axle housing, central single reduction with hub reduction and with differential locks between wheels and axles. Ratio::4.8 / 5.73 Optional:ST16,double reduction, speed ratio:3.93,4.42,4.8/ MCY13, 2 x 13000kgs |
Chassis |
Frame: U-profile parallel ladder frame with section of 300x80x8mm, and reinforced subframe all cold riveted cross members Front suspension:10 semi-elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer Rear suspension:12 leaf semi-elliptic springs, bogie spring and stabilizer |
Steering |
ZF power steering, model ZF8118, hydraulic steering with power assistance |
Overall Dimension |
10820 * 2550 * 3900mm |
Mixer tank effective volume |
Size:16cbm With Italian brand Bonfiglioli reduction gears, America brand Eton oil pump and motor |
Brake |
Service brake: dual circuit compressed air brake Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels Auxiliary brake: engine exhaust brake Optional:EVB, ABS, AUTOMATICSLACK ADJUSTER |
Tyres |
12.00R20,Radial (steel wire) Tires,1 spare tyre Option: 12.00-20, 12R22.5, 315/80R22.5, 12.00R24 |
Electrics |
Operating voltage: 24 V, negative grounded Starter: 24 V, 5.4 Kw Alternator: 3-phase, 28 V, 1500 W Batteries: 2 x 12 V, 165 Ah Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light |
Instrument Panel |
Active check central control with indicators, with this integral instrument the daily manual checks on the vehicle and combined indicators of compressed air pressure, coolant temperature, engine oil pressure and battery charging. |
Color |
Optional |
Profile of our company:
JINAN CMHAN TRUCK SALES CO.,LTD. is authorized truck dealer by China National Heavy Duty Truck Group Co., Ltd (CNHTC) in Shandong Province. It was founded in 2023, located in Jinan which is the famous production base of heavy duty truck in China. The 4 main functions of our company are truck&machinery&trailer sale, spare part supply, information feedback, and after-sales service.
The team of our company could provide all kinds of trucks and buses meeting the requirement of customers with the best price. We have many years of experience in supplying trucks,buses,trailers, strict quality management, fast and convenient channel of goods delivery, strict examination in quality and quantity of products, professional box packing, professional and reliable loading goods in containers, on-time delivery and competitive price.
Products of our company are sold all over China, and are exported to more than Eighty countries and regions such as Guinea,Nigeria,Benin,Central Africa,Mongolia ,DRC ,Mauritania ,Ghana ,Benin ,Angola ,Tanzania ,Congo ,South east Asia and Latin America. In a control of price and quality, our products are highly appreciated in these markets.
COMPANY ADVANTAGES:
| 1 | Rich Experience in sale of the Sinotruk’s heavy equipment & truck. |
| 2 | Expert in kinds of heavy trucks and spare parts. |
| 3 | Personalized customization to meet your working requirements. |
| 4 | High quality of Original parts & OEM services. |
| 5 | Engineers and experts on call for pre/after sale support. |
| 6 | One-stop service with heavy trucks, parts as well as stand-by advice & support. |
FAQ
Q:HOW CAN YOU INSURE MY MONEY BE SAFE?
A:Firstly you can send the money via trade assurances,Secondly We have worked in the field of truck sale for many years,and we have served thousands of buyer all over the world,We take the reputation as our life.we won’t deduct any money if the business break down in the end.
Q:WHAT’S YOUR MOQ AND DELIVERY TIME?
A:Usually,our MOQ is 1 sets,and our delivery time is within 30days for new placed order, and for stocked trucks our lead time is within 5 workdays.
Q:CAN I CHOOSE THE TRANSPORTATION METHOD BY MYSELF?
A:Yes,of course.But if CIF, you choose a different ships,that means the price will be different,(the price of bulk cargo ship is different from RO-RO ship )so the price will be changed,please notice that.
Q:DO YOU SUPPLY SPEAR PARTS?
A:Yes,we can provide all parts of the truck,like engine parts,electric parts,truck body parts and truck cabin parts.
Q:HOW CAN WE GET AFTER SALE SERVICE ?
A:We SINOTRUK Group has many overseas after sale service center, you can get services in these center,Also we can provide you technical support and parts supply,.
