Model: ZZ3167M3811W
Cabin: HW70, no sleeper with A/C
Engine: WD615.87, Euro 2, 290HP
Transmission: HW13710, 10F & 2R
Front Axle: HF9, 1x9000KG
Rear Axle: HC16, 1x16000KG
Body Size: 12 CBM
product Specifications:
Chassis Model |
ZZ3167M3811W |
Driving Type |
LHD (RHD is optional) |
Cabin |
HW70, without sleeper, two seats, double arm windscreen wiper system with three speeds, damped adjustable driver's seat, with heating and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn, air conditioner, with transverse stabilizer, with four piont support floating suspension+shock absorber. |
Engine |
Make: SINOTRUK Diesel 4-stroke direct injection diesel engine Engine model: WD615.87, Euro 2, 290 HP 6-cylinder in-line with water cooling, turbo-charging and intercooling Displacement: 9.726 L |
Transmission |
HW13710, 10F & 2R, with PTO Ratio:14.28, 10.62, 7.87, 5.88, 4.38, 3.27, 2.43, 1.80, 1.34, 1.00, 13.91(R1), 3.18(R2) |
Steering |
ZF power steering, modol ZF8118, hydraulic steering with power assitance |
Front Axle |
HF9,1x9000 KGS Steering with doubleT-cross section beam |
Rear Axle |
HC16, 1x16000 KGS Pressed axle housing, central single reduction with hub reduction,with differential locks between wheels and axles. Ratio:5.73 |
Propeller Shaft |
Double universal joint propeller shaft with gear-shaped coupling flange |
Chassis |
Frame: Uprofile parallel ladder frame with section of 300x80x8mm,reinforced subframe all cold riveted cross members Front suspension:10 semi elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer Rear suspension:12 leaf semi elliptic springs, bogie spring and stabilizer |
Brake |
Service brake: dual circuit compressed air brake Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels Auxiliary brake: engine exhaust brake |
Electrics |
Operating voltage: 24 V, negative grounded Starter: 24 V, 5.4 Kw Alternator: 3-phase, 28 V, 1500 W Batteries: 2 x 12 V, 165 Ah Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light |
Tyres |
12.00R20, radial tyres with one spare tyre |
Fuel Tank |
300L |
Cargo Body |
12 CBM, with hydraulic rear lift and seizing hand. |
Overall Dimension |
7300*2500*3500mm |
COMPANY ADVANTAGES:
1 |
Rich Experience in sale of the Sinotruk’s heavy equipment & truck. |
2 |
Expert in kinds of heavy trucks and spare parts. |
3 |
Personalized customization to meet your working requirements. |
4 |
High quality of Original parts & OEM services. |
5 |
Engineers and experts on call for pre/after sale support. |
6 |
One-stop service with heavy trucks, parts as well as stand-by advice & support. |
FAQ
Q:HOW CAN YOU INSURE MY MONEY BE SAFE?
A:Firstly you can send the money via trade assurances,Secondly We have worked in the field of truck sale for many years,and we have served thousands of buyer all over the world,We take the reputation as our life.we won’t deduct any money if the business break down in the end.
Q:WHAT’S YOUR MOQ AND DELIVERY TIME?
A:Usually,our MOQ is 1 sets,and our delivery time is within 30days for new placed order, and for stocked trucks our lead time is within 5 workdays.
Q:CAN I CHOOSE THE TRANSPORTATION METHOD BY MYSELF?
A:Yes,of course.But if CIF, you choose a different ships,that means the price will be different,(the price of bulk cargo ship is different from RO-RO ship )so the price will be changed,please notice that.
Q:DO YOU SUPPLY SPEAR PARTS?
A:Yes,we can provide all parts of the truck,like engine parts,electric parts,truck body parts and truck cabin parts.
Q:HOW CAN WE GET AFTER SALE SERVICE ?
A:We SINOTRUK Group has many overseas after sale service center, you can get services in these center,Also we can provide you technical support and parts supply,.
